Value Collection - 1/4" Bore Diam, 11/16" OD, Open Unground Full Complement Radial Ball Bearing - 1/4" Wide, 1 Row, Round Bore, 287 Lb Dynamic Capacity
Item #: 01376730
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Unground full complement radial ball bearings are used for moderate axial loads up to 1,500 RPMS. They are hardned for maximum shock resistance.
Open Bearing design without seals or shields and are intended to be lubricated in place and periodically maintained
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Unground Full Complement |
| Style | Open |
| Bore Diameter (Inch) | 1/4 |
| Bore Diameter (Decimal Inch) | 0.2500 |
| Outside Diameter (Inch) | 11/16 |
| Outside Diameter (Decimal Inch) | 0.6870 |
| Width (Inch) | 1/4 |
| Width (Decimal Inch) | 0.2500 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Carbon steel |
| Snap Ring Included | Without Snap Ring |
| Dynamic Load Capacity (Lb.) | 287 |
| Maximum RPM | 2500 |
