Browning - 6 Pitch, 5" Pitch Diam, 5.33" OD, 30 Tooth Spur Gear - 2" Face Width, 1-1/8" Bore Diam, 3-1/8" Hub Diam, 20° Pressure Angle, Steel
Item #: 02274561
Brand: Browning
Model #: YSS630
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Spur Gear |
| Number of Teeth | 30 |
| Hub Diameter (Decimal Inch) | 3.3800 |
| Hub Diameter (Inch) | 3-1/8 |
| Pitch Diameter (Decimal Inch) | 5.0000 |
| Bore Diameter (Inch) | 1-1/8 |
| Bore Diameter (Decimal Inch) | 1.1250 |
| Material | Steel |
| Face Width (Inch) | 2 |
| Face Width (Decimal Inch) | 2.0000 |
| Pressure Angle | 20 |
| PSC Code | 3020 |
