Seco - 59mm Cut Diam, 22mm Arbor Hole, 3.5mm Max Depth of Cut, 43° Indexable Chamfer & Angle Face Mill - 4 Inserts, OF.. 05.. Insert, Right Hand Cut, 4 Flutes, Series OctoMill
Item #: 02919678
Brand: Seco
Model #: 69159
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 59.00 |
| Cutting Diameter (Decimal Inch) | 2.3228 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Lead Angle | 43 |
| Overall Height (Decimal Inch) | 1.5748 |
| Overall Height (mm) | 40.00 |
| Insert Compatibility | OF.. 05.. |
| Series | OctoMill |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 3.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1378 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Number of Flutes | 4 |
| Cutting Rake Angle | 15 |
| Rake | Positive |
| Hub Diameter (Decimal Inch) | 1.8504 |
| Hub Diameter (mm) | 47.00 |
| Keyway Width (mm) | 10.40 |
| Keyway Width (Decimal Inch) | 0.4094 |
| Maximum Body Diameter (Decimal Inch) | 1.9685 |
| Maximum RPM | 11900 |
| Cutting Direction | Right Hand |
| Pitch | Normal |
| Complete Insert Compatibility | OFEX 05T305FR-E06; OFEX 05T305N-E04; OFEX 05T305N-M05; OFEX 05T305TN-D09; OFEX 05T305TN-M08; OFEX 05T305TN-ME07; OFMT 050405TR-M14; OFMT 050405TR-ME12 |
