Iscar - 12 Inserts, 10" Cut Diam, 2-1/2" Arbor Diam, 0.642" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 2-1/2" High, H490 AN.X 17 Insert Compatibility, Series Helido
Item #: 07051485
Brand: Iscar
Model #: 3105195
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 10.0000 |
| Arbor Hole Diameter (Decimal Inch) | 2.5000 |
| Lead Angle | 0/90 |
| Overall Height (Decimal Inch) | 2.5000 |
| Insert Compatibility | H490 AN.X 17 |
| Series | Helido |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.6420 |
| Number of Cutter Inserts | 12 |
| Insert Holding Method | Screw |
| Cutter Style | H490 F90AX-17 |
| Number of Flutes | 12 |
| Cutting Edge Length (Decimal Inch) | 0.6420 |
| Minimum Insert Radius (Decimal Inch) | 0.0160 |
| Complete Insert Compatibility | H490 ANKX/ANCX 1706-FF; H490 ANKX/ANCX-17 |
