Kitagawa - 3 Jaws, 12" Chuck Diam, Plain Back Mount, 3.5827" Through Hole, Drawbar, Hydraulic Power Lathe Chuck - 31,718 Lb Force per Jaw, 1.5mm x 60 Serrated Jaw Interface, 34mm to 304mm Jaw Capacity, 3,300 RPM, High Speed Steel Body
Item #: 08429516
Brand: Kitagawa
Model #: B212
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 304.80 |
| Chuck Diameter (Inch) | 12 |
| Number of Jaws | 3 |
| Mount | Plain Back |
| Through-Hole Diameter (mm) | 91.00 |
| Through-Hole Diameter (Decimal Inch) | 3.5827 |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (mm) | 34.00 |
| Maximum Jaw Capacity (mm) | 304.00 |
| Jaw Stroke Diameter (mm) | 10.60 |
| Piston Stroke Length (Decimal Inch) | 1.1810 |
| Maximum Drawbar Pulling Force (kN) | 55.00 |
| Maximum Static Gripping Force (kN) | 144.00 |
| Force Per Jaw (Lb.) | 31718.00 |
| Moment of Inertia (kgf/sq m) | 0.7380 |
| Maximum RPM | 3300 |
| Body Material | High Speed Steel |
| Power Cylinder Compatibility | S2091 |
| Includes | Chuck Assembled w/ Adapter; Chuck Mounting Bolts; Draw Nut Wrench; Jaw Mounting Bolts w/ Wrench; Soft Top Jaws; T-Nuts |
