Electro Hardware - #6-32, 1/8" OAL, 1/4" Across Flats, Aluminum Hex Male/Male Circuit Board Standoffs - 1/8" Body Length, Clear Finish
Item #: 08899130
Brand: Electro Hardware
Model #: MM1401M06MSC-1
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/male threads are externally threaded on both ends. The ends mate with internally threaded fasteners or other standoffs.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
| Product Specifications | |
|---|---|
| Thread Type | Male/Male |
| Material | Aluminum |
| System of Measurement | Inch |
| Body Shape | Hex |
| Overall Length (Inch) | 1/8 |
| Overall Length (Decimal Inch) | 0.1250 |
| Thread Size | #6-32 |
| Width Across Flats (Decimal Inch) | 0.2500 |
| Width Across Flats (Inch) | 1/4 |
| Finish/Coating | Clear |
| Body Length (Inch) | 1/8 |
| Body Length (Decimal Inch) | 0.1250 |
| Thread Length (Decimal Inch) | 0.2500; 0.3750 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Material Grade | T-3 |
| Fastener Standard | QQ-A-225A Comp 2 |
