Cle-Line - 9/16 to 1", 118° Point, Oxide Finish, High Speed Steel Reduced Shank Drill Bit Set
Item #: 57648321
Brand: Cle-Line
Model #: C22761
Features and Benefits
High Speed Steel (HSS) provides good wear resistance and can be used in general purpose applications on both ferrous and non-ferrous materials.
Round shanks with flats are ground flat on three sides for increased chuck grip, reducing slippage and help centering the drill in the chuck. They are used with portable drills and drill presses on ferrous and non-ferrous materials.
| Product Specifications | |
|---|---|
| System of Measurement | Inch |
| Drill Bit Material | High Speed Steel |
| Drill Bit Set Type | Reduced Shank Drill Bits |
| Minimum Drill Bit Size (Decimal Inch) | 0.5625 |
| Minimum Drill Bit Size (Inch) | 9/16 |
| Maximum Drill Bit Size (Decimal Inch) | 1.0000 |
| Maximum Drill Bit Size (Inch) | 1 |
| Drill Point Angle | 118 |
| Number of Pieces | 8 |
| Drill Bit Finish/Coating | Oxide |
| Drill Bit Size2 (Decimal Inch) | 0.5625; 0.6250; 0.6875; 0.7500; 0.8125; 0.8750; 0.9375; 1.0000 |
| Drill Bit Size (mm) | 14.29; 15.88; 17.46; 19.05; 20.64; 22.23; 23.81; 25.40 |
| Drill Bit Size (Inch) | 9/16; 5/8; 11/16; 3/4; 13/16; 7/8; 15/16; 1 |
| Material Set Type | Metalworking/Multipurpose Drill Bits |
| Overall Length (Inch) | (8) 6 |
| Point Type | Split Point |
| Step Increments (Inch) | 1/16 |
| Set Includes | (8) Reduced Shank Drills |
| Shank Type | Round with Flats |
| PSC Code | 5133 |
| Storage Unit Type | Case |
| Storage Unit Material | Metal |
| Through Coolant | No |
