Burndy - Ring Terminals; Terminal Type: Rectangle ; Insulation Type: NonInsulated ; Connection Type: Lug ; Compatible Wire Size (AWG): 4/0 (Strand) ; Compatible Wire Size (kcmil): 250-500 ; Stud Size (Inch): 1/2
Item #: 29228996
Brand: Burndy
Model #: KPA34
Product Specifications
Ring Terminals; Terminal Type: Rectangle ; Insulation Type: NonInsulated ; Connection Type: Lug ; Compatible Wire Size (AWG): 4/0 (Strand) ; Compatible Wire Size (kcmil): 250-500 ; Stud Size (Inch): 1/2
| Terminal Type | Rectangle |
| Insulation Type | NonInsulated |
| Connection Type | Lug |
| Compatible Wire Size (AWG) | 4/0 (Strand) |
| Compatible Wire Size (kcmil) | 250-500 |
| Stud Size (Inch) | 1/2 |
| Color | Tin |
| Contact Material | Copper |
| Insulation Material | NonInsulated |
| Ring Width (Inch) | 1.38 |
| Ring Width (Decimal Inch) | 1.38 |
| Overall Length (mm) | 84 |
| Contact Plating | Tin |
| Standards Met | CSA Certified; Prop 65 Notice; RoHS CM Compliant; UL 486A-486B; UL Listed |
