Indexable Chamfer & Angle Face Mills; Minimum Cutting Diameter (mm): 50.00; Maximum Cutting Diameter (mm): 51.00; Maximum Depth of Cut (mm): 9.00; Arbor Hole Diameter (mm): 22.00; Lead Angle: 88; Compatible Insert Size Code: SN.U1204; Cutter Style: R220.8
Item #: 29449675
Brand: Seco
Model #: 03091359
Product Specifications
| Minimum Cutting Diameter (mm) | 50.00 |
| Maximum Cutting Diameter (mm) | 51.00 |
| Maximum Depth of Cut (mm) | 9.00 |
| Arbor Hole Diameter (mm) | 22.00 |
| Lead Angle | 88 |
| Compatible Insert Size Code | SN.U1204 |
| Cutter Style | R220.88 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Rake | Negative (Axial); Negative (Radial) |
| Rake Angle | -8 |
| Series | -8 |
| Hub Diameter (mm) | 47.00 |
| Keyway Width (mm) | 10.40 |
| Overall Height (Mm - 5 Decimals) | 40.00 |
| Pitch Type | Normal |
| Maximum RPM | 12600 |
| Tool Application | Facing |
| Tool Performance | High Performance |
| Number Of Cutter Inserts | 4 |
| Coolant Through | Yes |
