Iscar - Arbor Hole Connection, 0.1783" Cutting Width, 1.5354" Depth of Cut, 160mm Cutter Diam, 1.5748" Hole Diam, 10 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFN, GSFU Insert
Item #: 30705198
Brand: Iscar
Model #: 2300957
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 4.53 |
| Cutting Width (Decimal Inch) | 0.1783 |
| Maximum Depth of Cut (mm) | 39.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.5354 |
| Cutter Diameter (mm) | 160.00 |
| Cutter Diameter (Decimal Inch) | 6.2992 |
| Hole Diameter (mm) | 40.00 |
| Hole Diameter (Decimal Inch) | 1.5748 |
| Number of Teeth | 10 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFN; GSFU |
| Staggered Tooth | No |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Clamp |
| Maximum RPM | 500 |
| Maximum Cutting Width (Decimal Inch) | 0.2165 |
| Maximum Cutting Width (mm) | 5.50 |
| Hub Diameter (mm) | 80.00 |
| Hub Diameter (Decimal Inch) | 3.1496 |
| Radius | No |
| Complete Insert Compatibility1 | GSFN 1.6; GSFN 2; GSFN 2.4; GSFN 2.4J; GSFN 3J; GSFU 1.4; GSFU 1.6; GSFU 1.7; GSFU 2.2; GSFU 3 |
