Iscar - 6 Inserts, 63mm Cut Diam, 27mm Arbor Diam, 13mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 45mm High, HM390 TDKT 1505.. Insert Compatibility, Through Coolant, Series HeliIQMill
Item #: 30708762
Brand: Iscar
Model #: 3106800
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 63.00 |
| Cutting Diameter (Decimal Inch) | 2.4803 |
| Arbor Hole Diameter (mm) | 27.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.0630 |
| Lead Angle | 0 |
| Overall Height (mm) | 45.00 |
| Overall Height (Decimal Inch) | 1.7717 |
| Insert Compatibility | HM390 TDKT 1505.. |
| Series | HeliIQMill |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 13.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.5118 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | HM390 FTD-15 |
| Hub Diameter (mm) | 59.00 |
| Hub Diameter (Decimal Inch) | 2.3228 |
| Keyway Width (mm) | 12.40 |
| Keyway Width (Decimal Inch) | 0.4882 |
| Counterbore Diameter (Decimal Inch) | 1.4961 |
| Complete Insert Compatibility | HM390 TDKT 150516-PDR; HM390 TDKT 150524PDR; HM390 TDKT 150532PDR; HM390 TDKT 1505PDR |
