Value Collection - 1" ID x 1-1/8" OD, EPDM O-Ring - 1/16" Thick, Round Cross Section
Item #: 31952955
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Round cross-section shapes can be used in both static and dynamic applications. They are used as a mechanical seal or gasket and are seated in a groove and compressed during assembly between two or more parts.
EPDM (Ethylene Propylene) is ideal for phosphate ester based hydraulic fluids. It provides resistance to weather, abrasion, hot water, steam, silicone fluids, dilute acids and dilute ketones. It is not resistant to petroleum fluids and diester lubricants.
| Product Specifications | |
|---|---|
| Cross Section Shape | Round |
| Material | EPDM |
| Dash Number | 022 |
| System of Measurement | Inch |
| Durometer (Shore A) | 65 - 75 |
| Inside Diameter (Inch) | 1 |
| Inside Diameter (Decimal Inch) | 1.0000 |
| Outside Diameter (Inch) | 1-1/8 |
| Outside Diameter (Decimal Inch) | 1.1250 |
| Thickness (Inch) | 1/16 |
| Maximum Temperature (F) | 300.000 |
| Minimum Temperature (F) | -65.000 |
