Kennametal - 2" Cut Diam, 3/4" Arbor Hole, 5.89mm Max Depth of Cut, 20° Indexable Chamfer & Angle Face Mill - 4 Inserts, SPHX 1205... Insert, 4 Flutes, Series Fix-Perfect
Item #: 32939852
Brand: Kennametal
Model #: 1724429
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 2 |
| Cutting Diameter (mm) | 50.80 |
| Cutting Diameter (Decimal Inch) | 2.0000 |
| Arbor Hole Diameter (mm) | 19.05 |
| Arbor Hole Diameter (Inch) | 3/4 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Lead Angle | 20 |
| Overall Height (Decimal Inch) | 1.7500 |
| Overall Height (mm) | 44.45 |
| Insert Compatibility | SPHX 1205... |
| Series | Fix-Perfect |
| Maximum Depth of Cut (mm) | 5.89 |
| Maximum Depth of Cut (Decimal Inch) | 0.2320 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Clamp |
| Cutter Style | CUFP |
| Number of Flutes | 4 |
| Hub Diameter (Decimal Inch) | 1.7500 |
| Maximum Body Diameter (Decimal Inch) | 2.5039 |
| Maximum RPM | 8595 |
| Complete Insert Compatibility | SPHX 1205ZC.R |
