Kennametal - 4" Cut Diam, 1-1/4" Arbor Hole, 5.5mm Max Depth of Cut, 46.5° Indexable Chamfer & Angle Face Mill - 10 Inserts, ON.X080608.. Insert, Right Hand Cut, 10 Flutes, Series MILL 16
Item #: 37737566
Brand: Kennametal
Model #: 6134104
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 4 |
| Cutting Diameter (mm) | 101.60 |
| Cutting Diameter (Decimal Inch) | 4.0000 |
| Arbor Hole Diameter (mm) | 31.76 |
| Arbor Hole Diameter (Inch) | 1-1/4 |
| Arbor Hole Diameter (Decimal Inch) | 1.2500 |
| Lead Angle | 46.5 |
| Overall Height (Inch) | 2 |
| Overall Height (Decimal Inch) | 2.0000 |
| Insert Compatibility | ON.X080608.. |
| Series | MILL 16 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 5.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.2150 |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Screw/Clamp |
| Number of Flutes | 10 |
| Hub Diameter (mm) | 80.00 |
| Maximum RPM | 6800 |
| Cutting Direction | Right Hand |
| Toolholder Material | Steel |
| Overall Length (Decimal Inch) | 2.0000 |
| Number of Flutes | 10 |
| Maximum RPM | 6800 |
| Toolholder Material | Steel |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.2500 |
