Kennametal - 8 Inserts, 80mm Cut Diam, 27mm Arbor Diam, 11mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 50mm High, LNGU110408SRGE Insert Compatibility, Through Coolant, Series Mill 4-11
Item #: 38161204
Brand: Kennametal
Model #: 6134234
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Arbor Hole Diameter (mm) | 27.00 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | LNGU110408SRGE |
| Series | Mill 4-11 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 11.00 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw/Clamp |
| Number of Flutes | 8 |
| Rake | Negative |
| Hub Diameter (mm) | 60.00 |
| Maximum Body Diameter (Decimal Inch) | 3.0670 |
| Maximum RPM | 17100 |
| Coolant Hole Diameter (Decimal Inch) | 0.0980 |
| Toolholder Material | Steel |
