Kennametal - 51mm Cut Diam, 22mm Arbor Hole, 4.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 4 Inserts, HNGJ 0905.. Insert, Right Hand Cut, 4 Flutes, Through Coolant, Series Dodeka
Item #: 41932989
Brand: Kennametal
Model #: 3647201
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 51.00 |
| Cutting Diameter (Decimal Inch) | 2.0079 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 1.5748 |
| Overall Height (mm) | 40.00 |
| Insert Compatibility | HNGJ 0905.. |
| Series | Dodeka |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1772 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | KSHR |
| Number of Flutes | 4 |
| Hub Diameter (Decimal Inch) | 1.5354 |
| Hub Diameter (mm) | 39.00 |
| Maximum Body Diameter (Decimal Inch) | 1.8720 |
| Maximum RPM | 15800 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | HNGJ 0905ANENLD |
