Iscar - Shank Connection, 0.276" Cutting Width, 7.9mm Depth of Cut, 32mm Cutter Diam, 4 Tooth Indexable Slotting Cutter - 0.63" Shank Diam, ETS-LN08 Toolholder, LNET Insert, Right Hand Cutting Direction
Item #: 45386836
Brand: Iscar
Model #: 3106147
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shank |
| Cutting Width (Decimal Inch) | 0.2760 |
| Maximum Depth of Cut (mm) | 7.90 |
| Cutter Diameter (mm) | 32.00 |
| Shank Diameter (mm) | 16.00 |
| Shank Diameter (Decimal Inch) | 0.6300 |
| Number of Teeth | 4 |
| Toolholder Style | ETS-LN08 |
| Series | Mini-TangSlot(ETS-LN08) |
| Insert Style | LNET |
| Number of Cutter Inserts | 2 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.2760 |
| Maximum Cutting Width (mm) | 8.00 |
| Cutting Radius (Inch) | 1/64 |
| Shank Length (Decimal Inch) | 3.2280 |
| Weldon Flat | Yes |
| Complete Insert Compatibility1 | LNET 081804-TN-N |
