Sandvik Coromant - TRVB1308 F Grade 2025 Carbide Turning Insert - TiCN/Al2O3/TiN Finish, 35° Triangle, 13mm Inscr Circle, 4.53mm Thick, 1/32" Corner Radius
Item #: 49423288
Brand: Sandvik Coromant
Model #: 5755539
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TRVB |
| Insert Size | 1308 |
| Material | Carbide |
| Length (mm) | 13.00 |
| Length (Decimal Inch) | 0.5118 |
| Inscribed Circle (mm) | 13.00 |
| Inscribed Circle (Decimal Inch) | 0.5118 |
| Thickness (Decimal Inch) | 0.1783 |
| Thickness (mm) | 4.53 |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (mm) | 0.79 |
| Corner Radius (Decimal Inch) | 0.0311 |
| Manufacturer's Grade | 2025 |
| Coating | TiCN/Al2O3/TiN |
| Chip Breaker | F |
| Hole Diameter (mm) | 3.40 |
| Hole Diameter (Decimal Inch) | 0.1339 |
| ISO Number | TRVB1308F2025 |
| Relief Angle | 5 |
| Coating Process | MTCVD |
| Manufacturers Catalog Number | 5755539 |
| Primary Workpiece Material | M |
| Included Angle | 35 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | CoroTurn TR |
| Maximum Depth of Cut (mm) | 12.20 |
| Maximum Depth of Cut (Decimal Inch) | 0.4803 |
| Insert Holding Method | Screw |
| Shape | Triangle |
