Square D - 1 NEMA Rated, DPST, 70 to 150 psi, Air Compressor Pressure and Level Switch - Fixed Pressure, 575 VAC, 1/4 NPT External Inch Connector, Screw Terminal, For Use with Square D Pumptrol
Item #: 49950249
Brand: Square D
Model #: 3FHG39J52M1XZ22
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Pressure Switch Type | Air Compressor |
| NEMA Rating | 1 |
| Maximum Pressure Setting | 150 psi |
| Minimum Pressure Setting | 70 psi |
| Differential Pressure Type | Fixed |
| Maximum Differential Pressure (psi) | 30.00 |
| Voltage | 575 VAC |
| Contact Form | DPST |
| Connector Size (Decimal Inch) | 0.2500 NPT external |
| Terminal Type | Screw |
| For Use With | Square D Pumptrol |
| Includes | 2 Way Pressure Release Valve; Maintained Manual Cut-in Lever (Auto-on) |
| Standards Met | CSA LR25490 Class 3211 06; UL Listed File E12158 CCN NKPZ |
