Iscar - Arbor Hole Connection, 0.56" Cutting Width, 1.075" Depth of Cut, 4" Cutter Diam, 1-1/4" Hole Diam, 10 Tooth Indexable Slotting Cutter - SDN-XN13 Toolholder, XNMU 13 Insert, Neutral Cutting Direction
Item #: 50099282
Brand: Iscar
Model #: 3106758
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.5600 |
| Maximum Depth of Cut (Decimal Inch) | 1.0750 |
| Cutter Diameter (Decimal Inch) | 4.0000 |
| Hole Diameter (Decimal Inch) | 1.2500 |
| Number of Teeth | 10 |
| Toolholder Style | SDN-XN13 |
| Series | Helislot(SDN-XN13) |
| Insert Style | XNMU 13 |
| Staggered Tooth | No |
| Number of Cutter Inserts | 10 |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Hub Diameter (Decimal Inch) | 1.7650 |
| Radius | No |
| Manufacturers Catalog Number | SDN D4.0-0.56-10-XN13 |
| Complete Insert Compatibility1 | XNMU 130608PNN-MM; XNMU 130608PNTN |
