Kyocera - 8 Inserts, 80mm Cut Diam, 14mm Arbor Diam, 45mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 90° Lead Angle, 70mm High, APMT 2506 Insert Compatibility
Item #: 50389121
Brand: Kyocera
Model #: 8820936
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Cutting Diameter (Decimal Inch) | 3.1496 |
| Arbor Hole Diameter (mm) | 14.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.5512 |
| Lead Angle | 90 |
| Overall Height (mm) | 70.00 |
| Overall Height (Decimal Inch) | 2.7559 |
| Insert Compatibility | APMT 2506 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 45.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.7717 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Cutter Style | MSR |
| Number of Flutes | 4 |
| Cutting Rake Angle | -8 |
| Rake | Negative |
| Keyway Width (mm) | 12.40 |
| Keyway Width (Decimal Inch) | 0.4882 |
| Keyway Depth (Decimal Inch) | 0.283465 |
| Keyway Depth (mm) | 7.20 |
| ISO Number | MSR080R-2M |
| Complete Insert Compatibility | APMT 250608ER-NB3; APMT 250608ER-NB4; APMT 250616EL-NB3; APMT 250616EL-NB4; APMT 250616ER-NB3; APMT 250616ER-NB3P; APMT 250616ER-NB4; APMT 250616ER-NB4P; APMT 250640ER-NB3; APMT 250640ER-NB4 |
