Kyocera - 6 Inserts, 63mm Cut Diam, 14mm Arbor Diam, 15.7mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 50mm High, BDMT 1704 Insert Compatibility, Through Coolant
Item #: 50390012
Brand: Kyocera
Model #: 8832577
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 63.00 |
| Cutting Diameter (Decimal Inch) | 2.4803 |
| Arbor Hole Diameter (mm) | 14.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.5512 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.00 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | BDMT 1704 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 15.70 |
| Maximum Depth of Cut (Decimal Inch) | 0.6181 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | MEC |
| Number of Flutes | 6 |
| Cutting Rake Angle | -7 |
| Rake | Negative |
| Keyway Width (mm) | 9.50 |
| Keyway Width (Decimal Inch) | 0.3740 |
| Keyway Depth (Decimal Inch) | 0.236220 |
| Keyway Depth (mm) | 6 |
| Maximum RPM | 14500 |
| Pitch | Fine |
| ISO Number | MEC063R-17-6T |
| Complete Insert Compatibility | BDMT 170402FR; BDMT 170404ER-JS; BDMT 170404ER-JT; BDMT 170404FR; BDMT 170404FR-JA; BDMT 170408ER-JS; BDMT 170408ER-JT; BDMT 170408FR-JA; BDMT 170412ER-JT; BDMT 170416ER-JT; BDMT 170420ER-JT; BDMT 170420FR-JA; BDMT 170424ER-JT; BDMT 170431ER-JT; BDMT 1704 |
