Kyocera - 5 Inserts, 50mm Cut Diam, 12mm Arbor Diam, 10mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 40mm High, BDMT 11T3 Insert Compatibility, Through Coolant
Item #: 50422518
Brand: Kyocera
Model #: 8819626
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 50.00 |
| Cutting Diameter (Decimal Inch) | 1.9685 |
| Arbor Hole Diameter (mm) | 12.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.4724 |
| Lead Angle | 0 |
| Overall Height (mm) | 40.00 |
| Overall Height (Decimal Inch) | 1.5748 |
| Insert Compatibility | BDMT 11T3 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 5 |
| Insert Holding Method | Screw |
| Cutter Style | MEC |
| Number of Flutes | 5 |
| Cutting Rake Angle | -7 |
| Rake | Negative |
| Keyway Width (mm) | 10.40 |
| Keyway Width (Decimal Inch) | 0.4094 |
| Keyway Depth (Decimal Inch) | 0.248031 |
| Keyway Depth (mm) | 6.30 |
| Maximum RPM | 22500 |
| Pitch | Standard |
| ISO Number | MEC050R-11-5T-M |
| Complete Insert Compatibility | BDMT 11T302ER-JS; BDMT 11T302ER-JT; BDMT 11T302FR; BDMT 11T302FR-JA; BDMT 11T304ER-JS; BDMT 11T304ER-JT; BDMT 11T304FR; BDMT 11T304FR-JA; BDMT 11T308ER-JS; BDMT 11T308ER-JT; BDMT 11T308FR-JA; BDMT 11T312ER-JT; BDMT 11T316ER-JT; BDMT 11T320ER-JT; BDMT 11T3 |
