Climax Metal Products - M4 Thread, 15mm Bore Diam, 1-3/16" OD, Shaft Locking Device - 6 Screws, 3,286 Lb Axial Load, 1-5/16" OAW, 0.472" Thrust Ring Width, 970 Ft/Lb Max Torque
Item #: 51320869
Brand: Climax Metal Products
Model #: C193M-15
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M4 |
| Bore Diameter (mm) | 15.000 |
| Outside Diameter (Decimal Inch) | 1.1875 |
| Thrust Ring Width (Decimal Inch) | 0.472 |
| Overall Width (Decimal Inch) | 1.3125 |
| Axial Load Lbs (Pounds) | 3286 |
| Maximum Torque (Ft/Lb) | 970 |
| Number of Screws | 6.000 |
| Contact Pressure on Hub (psi) | 15551.000 |
| Contact Pressure on Shaft (psi) | 31270.000 |
| Screw Seating Torque (In/Lb) | 528.000 |
