Sandvik Coromant - 5 Inserts, 2-1/2" Cut Diam, 1" Arbor Diam, 6.35mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 50mm High, RCKT 13 04 00 Insert Compatibility, Series CoroMill 200
Item #: 52071107
Brand: Sandvik Coromant
Model #: 5739043
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 63.50 |
| Cutting Diameter (Inch) | 2-1/2 |
| Cutting Diameter (Decimal Inch) | 2.5000 |
| Arbor Hole Diameter (mm) | 25.40 |
| Arbor Hole Diameter (Inch) | 1 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.00 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | RCKT 13 04 00 |
| Series | CoroMill 200 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 6.35 |
| Maximum Depth of Cut (Decimal Inch) | 0.2500 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 5 |
| Insert Holding Method | Screw |
| Cutter Style | RA200 |
| Number of Flutes | 5 |
| Rake | Negative |
| Hub Diameter (mm) | 25.40 |
| Hub Diameter (Decimal Inch) | 1.0000 |
| Hub Diameter (Inch) | 1 |
| Keyway Width (mm) | 9.75 |
| Keyway Width (Decimal Inch) | 0.3839 |
| Maximum Body Diameter (Decimal Inch) | 2.5000 |
| Number of Adjustable Pockets | 0 |
| Maximum RPM | 18000 |
| Pitch | Close |
| Cutting Edge Length (Inch) | 1/4 |
| Cutting Edge Length (Decimal Inch) | 0.2500 |
| ISO Number | RA200-063R25-13M |
| Complete Insert Compatibility | RCKT 13 04 00 |
| Toolholder Material | Steel |
