KIPP - 1/4-28, 10mm Thread Length, 3mm Plunger Diam, Hardened Locking Pin Knob Handle Indexing Plunger - Plunger Style A, 17mm Body Length, 31.5mm OAL, Steel
Item #: 52208469
Brand: KIPP
Model #: K0338.1903AJ
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 1/4-28 |
| Thread Length (mm) | 10.00 |
| Thread Length (Decimal Inch) | 0.3937 |
| Plunger Diameter (mm) | 3.00 |
| Plunger Diameter (Decimal Inch) | 0.1181 |
| Body Length (mm) | 17.00 |
| Body Length (Decimal Inch) | 0.6693 |
| Plunger Type | Hardened Locking Pin |
| Indexing Plunger Style Code | A |
| Lock Nut | No |
| Plunger Projection (mm) | 3.50 |
| Plunger Projection (Decimal Inch) | 0.1378 |
| Initial End Force (N) | 4.50 |
| Final End Force (N) | 10.00 |
| Knob Diameter (mm) | 14.00 |
| Knob Diameter (Decimal Inch) | 0.5512 |
| Distance Across Nut Flats (mm) | 8.00 |
| Distance Across Nut Flats (Decimal Inch) | 0.3150 |
| Nut Height (mm) | 5.00 |
| Nut Height (Decimal Inch) | 0.1969 |
| Overall Length (mm) | 31.50 |
| Overall Length (Decimal Inch) | 1.2402 |
| Tolerance (mm) | -0.04; -0.02 |
| Material | Steel |
| Finish/Coating | Black Oxide |
