KIPP - M24x2, 28mm Thread Length, 16mm Plunger Diam, Locking Pin Knob Handle Indexing Plunger - Plunger Style F, 32mm Body Length, 80mm OAL, Stainless Steel
Item #: 52215381
Brand: KIPP
Model #: K0341.12516
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M24x2 |
| Thread Length (mm) | 28.00 |
| Thread Length (Decimal Inch) | 1.1024 |
| Plunger Diameter (mm) | 16.00 |
| Plunger Diameter (Decimal Inch) | 0.6299 |
| Body Length (mm) | 32.00 |
| Body Length (Decimal Inch) | 1.2598 |
| Plunger Type | Non-Hardened Locking Pin |
| Indexing Plunger Style Code | F |
| Lock Nut | Yes |
| Plunger Projection (mm) | 16.00 |
| Plunger Projection (Decimal Inch) | 0.6299 |
| Initial End Force (N) | 20.00 |
| Final End Force (N) | 46.00 |
| Distance Across Nut Flats (mm) | 27.00 |
| Distance Across Nut Flats (Decimal Inch) | 1.0630 |
| Nut Height (mm) | 18.00 |
| Nut Height (Decimal Inch) | 0.7087 |
| Overall Length (mm) | 80.00 |
| Overall Length (Decimal Inch) | 3.1496 |
| Stud Thread Size | M10 |
| Tolerance (mm) | -0.04; -0.02 |
| Material | Stainless Steel |
| Finish/Coating | Natural |
