Iscar - Arbor Hole Connection, 0.5906" Depth of Cut, 63mm Cutter Diam, 0.3937" Hole Diam, 6 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSF. Insert
Item #: 52733839
Brand: Iscar
Model #: 2301352
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 15.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.5906 |
| Cutter Diameter (mm) | 63.00 |
| Cutter Diameter (Decimal Inch) | 2.4803 |
| Hole Diameter (mm) | 10.00 |
| Hole Diameter (Decimal Inch) | 0.3937 |
| Number of Teeth | 6 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSF. |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 1260 |
| Minimum Cutting Width (Decimal Inch) | 0.0709 |
| Maximum Cutting Width (Decimal Inch) | 0.1059 |
| Maximum Cutting Width (mm) | 2.69 |
| Hub Diameter (mm) | 32.00 |
| Hub Diameter (Decimal Inch) | 1.2598 |
