Sumitomo - 200mm Cut Diam, 47.63mm Arbor Hole, 45° Indexable Chamfer & Angle Face Mill - 16 Inserts, ONMT 05T6\xB6SNMT 13T6\xB6XNET 13T6 Insert, Right Hand Cut, Through Coolant, Series DualMill
Item #: 53966123
Brand: Sumitomo
Model #: 2200AGJ
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 200.00 |
| Cutting Diameter (Decimal Inch) | 7.8740 |
| Arbor Hole Diameter (mm) | 47.63 |
| Arbor Hole Diameter (Decimal Inch) | 1.8752 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | ONMT 05T6; SNMT 13T6; XNET 13T6 |
| Series | DualMill |
| Through Coolant | Yes |
| Number of Cutter Inserts | 16 |
| Insert Holding Method | Screw |
| Cutter Style | DGCF |
| Cutting Rake Angle | -10 (Radial); -5 (Axial) |
| Rake | Negative |
| Hub Diameter (Decimal Inch) | 5.9055 |
| Hub Diameter (mm) | 150.00 |
| Keyway Width (mm) | 25.40 |
| Keyway Width (Decimal Inch) | 1.0000 |
| Maximum Body Diameter (Decimal Inch) | 8.4252 |
| Cutting Direction | Right Hand |
| Pitch | Fine |
| Counterbore Diameter (Decimal Inch) | 5.1181 |
| Complete Insert Compatibility | ONMT 05T6ANER; SNMT 13T6ANER; XNET 13T6ANEN |
