Hubbell Wiring Device-Kellems - Pin & Sleeve Plugs & Connectors; Connector Type: Plug ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 60 ; Voltage: 480 VAC ; Maximum Cord Grip Diameter (mm): 36.80
Item #: 54033097
Brand: Hubbell Wiring Device-Kellems
Model #: HBL460P7W
Product Specifications
Pin & Sleeve Plugs & Connectors; Connector Type: Plug ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 60 ; Voltage: 480 VAC ; Maximum Cord Grip Diameter (mm): 36.80
| Connector Type | Plug |
| Pin Configuration | 4 |
| Number of Poles | 3 |
| Amperage | 60 |
| Voltage | 480 VAC |
| Maximum Cord Grip Diameter (mm) | 36.80 |
| Maximum Cord Grip Diameter (Decimal Inch) | 1.4500 |
| Minimum Cord Grip Diameter (mm) | 12.70 |
| Minimum Cord Grip Diameter (Decimal Inch) | 1/2 |
| Plug Diameter (mm) | 114 |
| Plug Diameter (Decimal Inch) | 4.4900 |
| Resistance Features | Impact Resistant; Moisture Resistant; Watertight |
| Color | Red |
| Overall Length (mm) | 257.80 |
| Overall Length (Decimal Inch) | 10.1500 |
| Number of Phases | 3 |
| Ingress Protection Rating | IP67 |
| Material | Nylon |
| Standards Met | CSA C22.2 No. 182.1; CSA Certified; CSA File LR280C; IEC 60309-1; RoHS Compliant; UL 1682; UL 1686C2; UL File E146033; UL Listed |
