Omron - 0.6 Amp at 125 VDC, 0.3 Amp at 250 VDC, 10 Amp at 250 VAC, SPDT, Pin Plunger, General Purpose Snap Action Switch - 250 VAC, Quick Connect Terminal, 14.2 Ounce Max Operating Force, 18.8mm High x 37.8mm Long x 10.3mm Wide, -13 to 176°F
Item #: 54045232
Brand: Omron
Model #: V-15G-1C26-K
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Switch Type | General Purpose |
| Maximum Amperage | 15 |
| Actuator Type | Pin Plunger |
| Contact Form | SPDT |
| Terminal Type | Quick Connect |
| Amperage at 250 VAC | 10 |
| Amperage at 125 VDC | 0.60 |
| Amperage at 250 VDC | 0.30 |
| Maximum Operating Force (oz.) | 14.20 |
| Minimum Release Force (oz.) | 2 |
| Voltage | 250 VAC |
| Maximum Operating Temperature (F) | 176 |
| Minimum Operating Temperature (F) | -13 |
| Overall Height (mm) | 18.80 |
| Overall Length (mm) | 37.80 |
| Overall Width (mm) | 10.30 |
| Contact Plating | Silver Alloy |
| Standards Met | CSA; RoHS Compliant; UL Recognized; VDE |
