Omron - 3 Amp at 30 VDC, 3 Amp at 125 VAC, 2 Amp at 250 VAC, SPDT, Hinge Lever, Sealed Miniature Snap Action Switch - 250 VAC, 30 VDC, Solder Terminal, 2.12 Ounce Max Operating Force, 0.47 Inch High x 0.78 Inch Long x 1/4 Inch Wide, -13 to 185°F
Item #: 54045331
Brand: Omron
Model #: D2SW-3L1HS
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Switch Type | Sealed Miniature |
| Maximum Amperage | 3 |
| Actuator Type | Hinge Lever |
| Contact Form | SPDT |
| Contact Configuration | NO/NC |
| Terminal Type | Solder |
| Amperage at 125 VAC | 3 |
| Amperage at 250 VAC | 2 |
| Amperage at 30 VDC | 3 |
| Maximum Operating Force (oz.) | 2.12 |
| Minimum Release Force (oz.) | 0.21 |
| Voltage | 250 VAC; 30 VDC |
| Maximum Operating Temperature (F) | 185 |
| Minimum Operating Temperature (F) | -13 |
| Overall Height (Decimal Inch) | 0.4700 |
| Overall Height (mm) | 12 |
| Overall Length (mm) | 19.80 |
| Overall Length (Decimal Inch) | 0.7800 |
| Overall Width (Decimal Inch) | 1/4 |
| Overall Width (mm) | 6.40 |
| Contact Plating | Silver |
| Standards Met | CSA; IEC 529; UL |
