Sandvik Coromant - CNMM543 PR Grade 4215 Carbide Turning Insert - TiCN/Al2O3/TiN Finish, 80° Parallelogram, 5/8" Inscr Circle, 1/4" Thick, 3/64" Corner Radius
Item #: 54748173
Brand: Sandvik Coromant
Model #: 5725749
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CNMM |
| Insert Size | 543 |
| Material | Carbide |
| Length (mm) | 14.92 |
| Length (Decimal Inch) | 0.5874 |
| Inscribed Circle (mm) | 15.88 |
| Inscribed Circle (Decimal Inch) | 0.6250 |
| Inscribed Circle (Inch) | 5/8 |
| Thickness (Inch) | 1/4 |
| Thickness (Decimal Inch) | 0.2500 |
| Thickness (mm) | 6.35 |
| Corner Radius (Inch) | 3/64 |
| Corner Radius (mm) | 1.1906 |
| Corner Radius (Decimal Inch) | 0.0469 |
| Manufacturer's Grade | 4215 |
| Coating | TiCN/Al2O3/TiN |
| Chip Breaker | PR |
| Insert Length (Decimal Inch) | 0.5874 |
| OverallLength (mm) | 16.12 |
| Overall Length (Decimal Inch) | 0.6346 |
| Hole Diameter (mm) | 6.35 |
| Hole Diameter (Decimal Inch) | 0.2500 |
| ISO Number | CNMM 16 06 12-PR 4215 |
| Relief Angle | 0 |
| Coating Process | MTCVD |
| Manufacturers Catalog Number | CNMM 16 06 12-PR 4215 |
| Included Angle | 80 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | T-Max P |
| Maximum Depth of Cut (mm) | 14.92 |
| Maximum Depth of Cut (Decimal Inch) | 0.5874 |
| Insert Holding Method | Pin & Clamp |
| Cutting Width (mm) | 14.92 |
| FullRadius | Yes |
| Multi Use Application | Turning |
| MultiUseTool | Yes |
| Shape | Parallelogram |
