Walter-Titex - 1/8" 180° Spiral Flute Solid Carbide Screw Machine Drill Bit
Item #: 00730762
Brand: Walter-Titex
Model #: 5564867
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high-speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Tinal is extremely wear resistant coating when used at high temperatures and speeds in a wide range of high strength applications. It is commonly used on steel, cast iron and non-ferrous metal. Tinal is a proprietary coating exclusive to Walter Titex.
Spiral flutes are constructed of a higher flute angle to remove chips easier.
| Product Specifications | |
|---|---|
| Drill Bit Size (Decimal Inch) | 0.1250 |
| Drill Bit Size (Inch) | 1/8 |
| Drill Point Angle | 180 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Tinal |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Flute Length (mm) | 12.00 |
| Flute Length (Decimal Inch) | 0.4724 |
| Overall Length (mm) | 62.00 |
| Overall Length (Decimal Inch) | 2.4409 |
| Flute Length x Diameter Ratio | 3xD |
| Point Type | Point Cutting |
| Shank Diameter (mm) | 6.00 |
| Shank Diameter (Decimal Inch) | 0.2362 |
| Specification Designation | DIN |
| Maximum Drilling Depth (mm) | 5.00 |
| Maximum Drilling Depth (Decimal Inch) | 0.1969 |
| Spiral Type | Regular Spiral |
| Shank Length (mm) | 42.00 |
| Shank Length (Decimal Inch) | 1.6535 |
| Threaded Shank | No |
| Number of Flutes | 2 |
| Drill Point Length (mm) | 0.10 |
| Drill Point Length (Decimal Inch) | 0.0039 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (mm) | p7 |
| Drill Tip Finish/Coating | None |
| Specification Number | DIN 6535HA |
| Web Thinning | Web-Thinned |
| Material Grade | K30F |
| Series/List | A7191TFT |
| Length Type | Regular |
