Schneider Electric - 16mm Mount Hole, Flush, Pushbutton Switch with Contact Block - Rectangle, Yellow Pushbutton, Illuminated, Momentary (MO)
Item #: 56697584
Brand: Schneider Electric
Model #: XB6DW5B1B
Exact Tooling IR#: 04
Features and Benefits
Pushbutton switches with contact blocks are designed to activate machinery by button that is pressed and released. The contact block controls the flow of electricity through the switch.
Illuminated pushbuttons offer a light within the button fo added safety in darker areas.
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (mm) | 16 |
| Switch Type | Pushbutton Switches with Contact Blocks |
| Pushbutton Type | Flush |
| Pushbutton Shape | Rectangle |
| Pushbutton Color | Yellow |
| Operator Illumination | Illuminated |
| Operation Type | Momentary (MO) |
| Amperage | 0.10 @ 250 V; 0.22 @ 125 V; 1.50 @ 240 V; 3 @ 120 V |
| Voltage | 120 V @ 3 A; 125 V @ 0.22 A; 240 V @ 1.50 A; 250 V @ 0.10 A |
| Contact Configuration | NO |
| Terminal Type | Quick Connect |
| NEMA Rating | 4; 13; 4X |
| Lamp Type | LED |
| Standards Met | CCC; CSA; CSA C22.2 No. 14; EN/IEC 60947-1; EN/IEC 60947-5-1; EN/IEC 60947-5-5; GOST; JIS C 4520; JIS C 852; UL |
