Square D - 110 Coil VAC at 50 Hz, 120 Coil VAC at 60 Hz, 27 Amp, NEMA Size 1, Reversible Enclosed Enclosure NEMA Motor Starter - 10 hp at 1 Phase, 1 Enclosure Rating
Item #: 56813264
Brand: Square D
Model #: 8736SCG8V02H30S
Exact Tooling IR#: 04
Features and Benefits
Enclosed housings are designed to ensure that the motor is never disconnected from power during starting. Ideal for frictional loads and prevention of electrical shocks and dust.
Reversing starters are designed with three individual lines that connect to and run voltage through a motor. Each line alternates in a sequence as they reach their voltage peak. They are used to reverse the rotation of a motor.
NEMA 1 refers to enclosures constructed for indoor use. They provide a degree of protection from falling and other solid objects entering the enclosure.
| Product Specifications | |
|---|---|
| Amperage | 27 |
| NEMA Size | 1 |
| Coil Voltage | 110 VAC @ 50 Hz; 120 VAC @ 60 Hz |
| Enclosure Type | Enclosed |
| Action | Reversible |
| NEMA Enclosure Rating | 1 |
| Horsepower at 1 Phase | 10 |
| Overall Height (mm) | 302 |
| Overall Height (Decimal Inch) | 11.8800 |
| Overall Width (mm) | 302 |
| Overall Width (Decimal Inch) | 11.8800 |
| Overall Depth (mm) | 191 |
| Overall Depth (Decimal Inch) | 7.5300 |
| Standards Met | CSA File No. LR60905 Class 3211 04; UL Listed File No. E78351 CCN NLDX |
