Cle-Line - 61/64" Drill, 118° Point, High Speed Steel Silver Deming & Reduced Shank Drill Bit
Item #: 57633976
Brand: Cle-Line
Model #: C17059
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications on both ferrous and nonferrous materials.
Oxide/Gold provides a polished finish and prevents chip building, galling and welding on a workpiece. It is commonly used in several applications on low carbons, stainless steel and iron based ferrous metals.
Round shanks with flats are ground flat on three sides for increased chuck grip, reducing slippage and help centering the drill in the chuck. They are used with portable drills and drill presses on ferrous and non-ferrous materials.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Spiral flute reamers are used in blind and through-hole operations. They are used to bridge interrupted cuts.
Regular, also known as medium spiral bits, are used in general purpose applications. They are used on soft, nonferrous materials.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 61/64 |
| Drill Bit Size (Decimal) | 0.9531 |
| Shank Diameter (Inch) | 1/2 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Oxide/Gold |
| Overall Length (Inch) | 6 |
| Overall Length (Decimal Inch) | 6 |
| Shank Type | With Flats |
| Flute Length (mm) | 79.38 |
| Flute Type | Spiral |
| Through Coolant | No |
| Cutting Direction | Right Hand |
| Point Type | Split Point |
| Point Type | Split Point |
| Flute Type | Spiral |
| Spiral Type | Regular Spiral |
| Spiral Type | Regular Spiral |
| Number of Flats | 3 |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0012 |
| Drill Bit Grade | General Purpose |
| Series/List | 1877 |
| Series/List | 1877 |
| Spiral Type | Regular Spiral |
| Overall Length (Inch) | 6 |
| Flute Type | Spiral |
| Drill Point Angle | 118 |
| Cutting Direction | Right Hand |
