Seco - Arbor Hole Connection, 0.2756" Cutting Width, 1.047" Depth of Cut, 100mm Cutter Diam, 1-1/16" Hole Diam, 5 Tooth Indexable Slotting Cutter - 335.19 Toolholder, SNHQ 1204 Insert
Item #: 60153145
Brand: Seco
Model #: 12670
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 7.00 |
| Cutting Width (Decimal Inch) | 0.2756 |
| Maximum Depth of Cut (mm) | 26.59 |
| Maximum Depth of Cut (Decimal Inch) | 1.0470 |
| Cutter Diameter (mm) | 100.00 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Hole Diameter (mm) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.0630 |
| Number of Teeth | 5 |
| Toolholder Style | 335.19 |
| Series | 335.19 |
| Insert Style | SNHQ 1204 |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Screw |
| Maximum RPM | 7500 |
| Minimum Cutting Width (Decimal Inch) | 0.2756 |
| Maximum Cutting Width (Decimal Inch) | 0.3150 |
| Maximum Cutting Width (mm) | 8.00 |
| Radius | No |
| Rake | Negative |
| Cutter Body Width (mm) | 12.00 |
| Cutter Body Width (Decimal Inch) | 0.4724 |
| Complete Insert Compatibility1 | SNHQ 120402TL4-M07; SNHQ 120402TR4-M07; SNHQ 120404EL4-E05; SNHQ 120404ER4-E05; SNHQ 120404TL4-M07; SNHQ 120404TR4-M07; SNHQ 120408TL4-M07; SNHQ 120408TR4-M07; SNHQ 120412TL4-M07; SNHQ 120412TR4-M07; SNHQ 120416TL4-M07; SNHQ 120416TR4-M07; SNHQ 120420TL4- |
