Iscar - Shell Mount B Connection, 1/2" Cutting Width, 1.07" Depth of Cut, 4" Cutter Diam, 1" Hole Diam, 6 Tooth Indexable Slotting Cutter - FDN Toolholder, X/QPMT 100408PDTN Insert
Item #: 60467156
Brand: Iscar
Model #: 3100918
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount B |
| Cutting Width (Decimal Inch) | 0.5000 |
| Cutting Width (Inch) | 1/2 |
| Maximum Depth of Cut (Decimal Inch) | 1.0700 |
| Cutter Diameter (Decimal Inch) | 4.0000 |
| Cutter Diameter (Inch) | 4 |
| Hole Diameter (Inch) | 1 |
| Hole Diameter (Decimal Inch) | 1.0000 |
| Number of Teeth | 6 |
| Toolholder Style | FDN |
| Series | Heliquad(FDN) |
| Insert Style | X/QPMT 100408PDTN |
| Number of Cutter Inserts | 12 |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.5000 |
| Maximum Cutting Width (Decimal Inch) | 0.5000 |
| Hub Diameter (Decimal Inch) | 2.1600 |
| Radius | No |
| Manufacturers Catalog Number | FDN D4.0-0.50-08-R10 |
