Associated Spring Raymond - 0.3228" ID, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.5906" OD, 0.0492" High, 0.0315" Thick
Item #: 61411831
Brand: Associated Spring Raymond
Model #: BD0150800082S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| System of Measurement | Metric |
| Inside Diameter (Decimal Inch) | 0.3228 |
| Inside Diameter (mm) | 8.20 |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Outside Diameter (Decimal Inch) | 0.5906 |
| Outside Diameter (mm) | 15.00 |
| Thickness (mm) | 0.80 |
| Thickness (Decimal Inch) | 0.0315 |
| Overall Height (mm) | 1.25 |
| Overall Height (Decimal Inch) | 0.0492 |
| Deflection (Decimal Inch) | 0.0134 |
| Deflection (mm) | 0.34 |
| Load at Deflection (Lb.) | 231.33 |
| Load at Deflection (N) | 1029.00 |
| Finish/Coating | Uncoated |
| Fastener Standard | DIN 2093 |
