Value Collection - 22 to 16 AWG Compatible, Nylon Fully Insulated, Crimp-On Butt Splice Terminal - 2 Wire Entries, Copper Contacts, 1" OAL, Red
Item #: 61565354
Brand: Value Collection
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Insulation Type | Fully Insulated |
| Insulation Material | Nylon |
| Connection Type | Crimp-On |
| Compatible Wire Size (sq mm) | 0.50-1.50 |
| Compatible Wire Size (AWG) | 22-16 |
| Color | Red |
| Overall Length (mm) | 25.20 |
| Overall Length (Decimal Inch) | 0.9920 |
| Overall Diameter (mm) | 4 |
| Overall Diameter (Decimal Inch) | 0.1570 |
| Number of Wire Entries | 2 |
| Contact Material | Copper |
| Standards Met | cUL Listed; ROHS Compliant; UL Listed |
