Climax Metal Products - M4 Thread, 14mm Bore Diam, 28mm OD, Shaft Locking Device - 4 Screws, 2,191 Lb Axial Load, 1.26" OAW, 0.551" Thrust Ring Width, 50 Ft/Lb Max Torque
Item #: 64642457
Brand: Climax Metal Products
Model #: C133M-14X28
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M4 |
| Bore Diameter (Decimal Inch) | 0.5510 |
| Bore Diameter (mm) | 14.000 |
| Outside Diameter (Decimal Inch) | 1.1020 |
| Outside Diameter (mm) | 28.0000 |
| Thrust Ring Width (Decimal Inch) | 0.551 |
| Overall Width (Decimal Inch) | 1.2600 |
| Axial Load Lbs (Pounds) | 2191 |
| Maximum Torque (Ft/Lb) | 50 |
| Number of Screws | 4.000 |
| Contact Pressure on Hub (psi) | 9564.000 |
| Contact Pressure on Shaft (psi) | 19127.000 |
| Screw Seating Torque (In/Lb) | 44.400 |
