Climax Metal Products - M6 Thread, 1-1/4" Bore Diam, 76mm OD, Shaft Locking Device - 8 Screws, 17,107 Lb Axial Load, 3" OAW, 1.654" Thrust Ring Width, 891 Ft/Lb Max Torque
Item #: 64649833
Brand: Climax Metal Products
Model #: C600E-125
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (Inch) | 1-1/4 |
| Bore Diameter (Decimal Inch) | 1.2500 |
| Outside Diameter (Decimal Inch) | 2.9920 |
| Outside Diameter (mm) | 76.0000 |
| Thrust Ring Width (Decimal Inch) | 1.654 |
| Overall Width (Decimal Inch) | 2.9920 |
| Axial Load Lbs (Pounds) | 17107 |
| Maximum Torque (Ft/Lb) | 891 |
| Number of Screws | 8.000 |
| Screw Seating Torque (In/Lb) | 108.000 |
