Climax Metal Products - M6 Thread, 7/8" Bore Diam, 60mm OD, Shaft Locking Device - 5 Screws, 10,697 Lb Axial Load, 2.362" OAW, 1.339" Thrust Ring Width, 390 Ft/Lb Max Torque
Item #: 64650237
Brand: Climax Metal Products
Model #: C600E-087
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (Inch) | 7/8 |
| Bore Diameter (Decimal Inch) | 0.8750 |
| Outside Diameter (Decimal Inch) | 2.3620 |
| Outside Diameter (mm) | 60.0000 |
| Thrust Ring Width (Decimal Inch) | 1.339 |
| Overall Width (Decimal Inch) | 2.3620 |
| Axial Load Lbs (Pounds) | 10697 |
| Maximum Torque (Ft/Lb) | 390 |
| Number of Screws | 5.000 |
| Screw Seating Torque (In/Lb) | 108.000 |
