Seco - Shell Mount Connection, 1.0236" Cutting Width, 1.7244" Depth of Cut, 160mm Cutter Diam, 1.5748" Hole Diam, 5 Tooth Indexable Slotting Cutter - R335.25 Toolholder, L/XNHQ 1407 Insert, Right Hand Cutting Direction
Item #: 65943425
Brand: Seco
Model #: 76799
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount |
| Cutting Width (mm) | 26.00 |
| Cutting Width (Decimal Inch) | 1.0236 |
| Maximum Depth of Cut (mm) | 43.80 |
| Maximum Depth of Cut (Decimal Inch) | 1.7244 |
| Cutter Diameter (mm) | 160.00 |
| Cutter Diameter (Decimal Inch) | 6.2992 |
| Hole Diameter (mm) | 40.00 |
| Hole Diameter (Decimal Inch) | 1.5748 |
| Number of Teeth | 5 |
| Toolholder Style | R335.25 |
| Series | R335.25 |
| Insert Style | L/XNHQ 1407 |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 10 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 4400 |
| Minimum Cutting Width (Decimal Inch) | 0.8268 |
| Maximum Cutting Width (Decimal Inch) | 1.0236 |
| Maximum Cutting Width (mm) | 26.00 |
| Hub Diameter (mm) | 70.00 |
| Hub Diameter (Decimal Inch) | 2.7559 |
| Radius | No |
| Complete Insert Compatibility1 | LNHQ 140708TN4-M11; LNHQ 140731TN4-M11; LNHQ 140740TN4-M11; LNHQ 140750TN4-M11; LNHQ 140760TN4-M11; XNHQ 140708EN4-E10; XNHQ 140708TN4-M11; XNHQ 140716TN4-M11; XNHQ 140720TN4-M11; XNHQ 140724TN4-M11; XNHQ 140731TN4-M11; XNHQ 140740TN4-M11; XNHQ 140750TN4- |
