Kitagawa - 3 Jaws, 10" Chuck Diam, A2-8 Mount, 2.953" Through Hole, Drawbar, Hydraulic Power Lathe Chuck - 24,449 Lb Force per Jaw, 1.5mm x 60 Serrated Jaw Interface, 31mm to 254mm Jaw Capacity, 4,200 RPM, High Speed Steel Body
Item #: 67295949
Brand: Kitagawa
Model #: B210
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 254.00 |
| Chuck Diameter (Inch) | 10 |
| Chuck Diameter (Decimal Inch) | 10.0000 |
| Number of Jaws | 3 |
| Mount | A2-8 |
| Through-Hole Diameter (mm) | 75.01 |
| Through-Hole Diameter (Decimal Inch) | 2.9530 |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (mm) | 31.00 |
| Maximum Jaw Capacity (mm) | 254.00 |
| Jaw Stroke Diameter (mm) | 8.79 |
| Jaw Stroke Diameter (Decimal Inch) | 0.3460 |
| Piston Stroke Length (Decimal Inch) | 0.9840 |
| Maximum Drawbar Pulling Force (kN) | 43.00 |
| Maximum Drawbar Pulling Force (Lb.) | 9666.78 |
| Maximum Static Gripping Force (kN) | 111.00 |
| Maximum Static Gripping Force (Lb.) | 24953.79 |
| Force Per Jaw (Lb.) | 24449.00 |
| Moment of Inertia (kgf/sq m) | 0.3230 |
| Maximum RPM | 4200 |
| Body Material | High Speed Steel |
| Power Cylinder Compatibility | S1875 |
| Includes | Chuck Assembled w/ Adapter; Chuck Mounting Bolts; Draw Nut Wrench; Jaw Mounting Bolts w/ Wrench; Soft Top Jaws; T-Nuts |
