Kitagawa - 2 Jaws, 5" Chuck Diam, Plain Back Mount, 1.299" Through Hole, Drawbar, Hydraulic Power Lathe Chuck - 8,090 Lb Force per Jaw, 1.5mm x 60 Serrated Jaw Interface, 12mm to 135mm Jaw Capacity, 7,000 RPM, High Speed Steel Body
Item #: 67296004
Brand: Kitagawa
Model #: BT205
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 127.00 |
| Chuck Diameter (Inch) | 5 |
| Number of Jaws | 2 |
| Mount | Plain Back |
| Through-Hole Diameter (mm) | 32.99 |
| Through-Hole Diameter (Decimal Inch) | 1.2990 |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (mm) | 12.00 |
| Maximum Jaw Capacity (mm) | 135.00 |
| Jaw Stroke Diameter (mm) | 5.41 |
| Jaw Stroke Diameter (Decimal Inch) | 0.2130 |
| Piston Stroke Length (Decimal Inch) | 0.4720 |
| Maximum Drawbar Pulling Force (kN) | 11.70 |
| Maximum Drawbar Pulling Force (Lb.) | 2630.26 |
| Maximum Static Gripping Force (kN) | 24.00 |
| Maximum Static Gripping Force (Lb.) | 5395.41 |
| Force Per Jaw (Lb.) | 8090.00 |
| Moment of Inertia (kgf/sq m) | 0.0170 |
| Maximum RPM | 7000 |
| Body Material | High Speed Steel |
| Power Cylinder Compatibility | F0933H |
| Includes | Chuck Assembled w/ Adapter; Chuck Mounting Bolts; Draw Nut Wrench; Jaw Mounting Bolts w/ Wrench; Soft Top Jaws; T-Nuts |
