Kitagawa - 2 Jaws, 6" Chuck Diam, Plain Back Mount, 1.7717" Through Hole, Drawbar, Hydraulic Power Lathe Chuck - 12,555 Lb Force per Jaw, 1.5mm x 60 Serrated Jaw Interface, 14mm to 169mm Jaw Capacity, 6,000 RPM, High Speed Steel Body
Item #: 67296012
Brand: Kitagawa
Model #: BT206
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 152.40 |
| Chuck Diameter (Inch) | 6 |
| Number of Jaws | 2 |
| Mount | Plain Back |
| Through-Hole Diameter (mm) | 45.00 |
| Through-Hole Diameter (Decimal Inch) | 1.7717 |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (mm) | 14.00 |
| Maximum Jaw Capacity (mm) | 169.00 |
| Jaw Stroke Diameter (mm) | 5.50 |
| Piston Stroke Length (Decimal Inch) | 0.5910 |
| Maximum Drawbar Pulling Force (kN) | 14.50 |
| Maximum Static Gripping Force (kN) | 38.00 |
| Force Per Jaw (Lb.) | 12555.00 |
| Moment of Inertia (kgf/sq m) | 0.0560 |
| Maximum RPM | 6000 |
| Body Material | High Speed Steel |
| Power Cylinder Compatibility | S1246 |
| Includes | Chuck Assembled w/ Adapter; Chuck Mounting Bolts; Draw Nut Wrench; Jaw Mounting Bolts w/ Wrench; Soft Top Jaws; T-Nuts |
