Electro Hardware - 0.194" ID x 3/8" OD, #10 Screw, Brass Female Unthreaded Circuit Board Spacer - Round Body, Zinc-Plated Finish, 1" OAL
Item #: 67715748
Brand: Electro Hardware
Model #: S1111-M01-F21-I
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Brass is an alloy of copper and zinc that is durable, nonmagnetic and conductive.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Brass |
| System of Measurement | Inch |
| Body Shape | Round |
| Screw Size | #10 |
| Outside Diameter (Decimal Inch) | 0.3750 |
| Outside Diameter (Inch) | 3/8 |
| Overall Length (Inch) | 1 |
| Inside Diameter (Decimal Inch) | 0.194 |
| Finish/Coating | Zinc-Plated |
| Inside Diameter Tolerance (Decimal Inch) | 0.000 to 0.010 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | ASTM B633; QQ-B-626 Comp 22; Type 1 |
