Electro Hardware - 0.141" ID x 1/4" OD, #6 Screw, Grade T-3 Aluminum Female Unthreaded Circuit Board Spacer - Round Body, Uncoated, 5/8" OAL
Item #: 67716589
Brand: Electro Hardware
Model #: S537-M04-F16-G
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Aluminum |
| System of Measurement | Inch |
| Body Shape | Round |
| Screw Size | #6 |
| Outside Diameter (Decimal Inch) | 0.2500 |
| Outside Diameter (Inch) | 1/4 |
| Overall Length (Decimal Inch) | 0.6250 |
| Overall Length (Inch) | 5/8 |
| Inside Diameter (Decimal Inch) | 0.141 |
| Finish/Coating | Uncoated |
| Material Grade | T-3 |
| Inside Diameter Tolerance (Decimal Inch) | 0.000 to 0.010 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | QQ-A-225A Comp 2 |
